Avery Dennison® 800 Premium Cast
Avery Dennison® 800 Premium Cast is a unique long-life film range that offers excellent dimensional stability. The face film allows for easy and accurate application of finished lettering and graphics to curved and corrugated surfaces.
Avery Dennison® 800 Premium Cast White and 830 Premium Cast White Matte are manufactured on a blue contrast backing paper for ease of conversion.
Physical Characteristics
| Product | Test Method¹ | Results |
|---|---|---|
| Caliper, facefilm (micron) | ISO 534 | 50 |
| Caliper, facefilm + adhesive (micron) | ISO 534 | 75 |
| Gloss (GU) | ISO 2813 | Gloss 20° 50% / Matt 85° 20% |
| Dimensional stability (mm max.) | FINAT FTM 14 | 0.20 |
| Shelf life (years) | Stored at 22°C / 50% RH | 2 |
| Durability² (Vertical exposure, zone 1) | ||
| – Black & White | 10 years | |
| – All Colours & Transparent | 8 years | |
| – Metallics | 5 years |
Adhesive
| Property | Test Method | Result |
|---|---|---|
| Elongation (%) | DIN 53455 | 130 |
| Adhesion, initial (N/m) | FINAT FTM-1, stainless steel | 500 |
| Adhesion, after 24 hours (N/m) | FINAT FTM-1, stainless steel | 600 |
| Flammability | Self-extinguishing | |
| Accelerated ageing | SAE J 1960, 2000h exposure | No negative impact on film performance |
Temperature Range
| Condition | Value |
|---|---|
| Application temperature (min. °C) | +10 |
| Service temperature (°C to °C) | -40 to +110 |
Chemical Properties
| Test | Exposure | Result |
|---|---|---|
| Humidity resistance | 200 hours exposure | No effect |
| Salt spray resistance | 120 hours exposure | No effect |
| Water resistance | 48 hours immersion | No effect |
